Q ERECTOR (ERECTOR 22) SUPPRESSOR - MODULAR .22 LR RIMFIRE SILENCER, TUBELESS, PISTOL AND RIFLE
The Q Erector, also known as the Erector 22, is a fully modular, tubeless .22 LR rimfire suppressor you can run short, long, or anywhere in between. Depending on configuration, it measures 1.9" to 7.6" long and weighs 2.6 to 4.3 oz, with a 1" diameter, aluminum and stainless steel construction, and a 1/2x28 direct thread mount. Q rates it for .22 rimfire and smaller.
Instead of an outer tube, the Erector is built from an aluminum rear mount, a stainless steel blast baffle, nine aluminum baffles, and an aluminum front cap, each threading to the next. Run every baffle for maximum suppression or pull some to shorten it, with the tubeless design adding internal volume along the way. Q rates the Erector at 115 dB with all 10 baffles on a 3.5" barrel and 114 dB on a 16" barrel, both with CCI Standard Velocity, and says that even fully assembled it weighs less than a standard QD sling swivel and cup.
The Erector works just as well on rimfire pistols as it does on rifles. It ships with two assembly tools and a spacer for barrel threads longer than .625", and Q recommends cleaning it every 1,000 rounds. For 5.7x28 and hotter rimfire, the Q El Camino is the better fit, and the Q Erect9r brings the same modular concept to 9mm.
CAPITOL ARMORY'S OPINION
The Erector brought a level of modularity to rimfire suppressors that the industry really hadn't seen before. A lot of shooters don't know exactly what they want in a can until they've put some rounds through a few, and even then, you might want something short and handy one day and as quiet as possible the next. Different jobs call for different tools.
With the Erector, you don't have to compromise. Want it tiny on a pistol for plinking? Pull a few baffles. Taking a rifle out and want it as quiet as it gets? Run all of them. It's light enough that you'll barely notice it either way. Just use the included tools when you take it apart, since Q is pretty serious about that. If you're shooting 5.7x28 or hotter rimfire, the El Camino is the one to grab, and if you love the idea for your 9mm pistol, check out the Erect9r.
FEATURES
- Length: 1.9" to 7.6"
- Weight: 2.6 to 4.3 oz
- Mount: 1/2x28 direct thread
- Caliber rating: .22 LR, rated for .22 rimfire and smaller (not rated for 5.7x28)
- Finishes: Clear Anodize, Black Nitride
- Diameter: 1"
- Tubeless modular design with a rear mount, stainless steel blast baffle, nine aluminum baffles, and front cap
- Materials: 7075-T6 aluminum and 17-4 stainless steel
- Works on rimfire pistols and rifles
- Includes a spacer for barrel threads longer than .625"
- User serviceable with the included tools, with Q recommending cleaning every 1,000 rounds
- Models: SIL-ER-22 (Clear Anodize), SIL-ER-22-BLK (Black Nitride)
WHAT'S INCLUDED
- Q Erector (fully assembled)
- Assembly tools (2)
- Thread spacer
- Storage pouch
MEDIA
SOUND PERFORMANCE
- .22 LR: 115 dB, all 10 baffles, 3.5" barrel, CCI Standard Velocity (Q)
- .22 LR: 114 dB, all 10 baffles, 16" barrel, CCI Standard Velocity (Q)
AVAILABLE MODELS
Finishes: Clear Anodize, Black Nitride
| Part Number | SIL-ER-22 |
|---|---|
| Weight | 4.3oz |
| Manufacturer | Q |
| Caliber | .22 lr |
| Length | 7.6" |
| Diameter | 1.0" |
| Decibel Reduction / Output | 114dB |
| Full Auto Rated | No |
| Mount | Direct Connect / Thread On |
| Thread Pitch | 1/2x28 |
| Materials | Stainless Steel, Aluminum |
| Can Be Disassembled | Yes |
| Warranty | Lifetime |
